Thông số kỹ thuật
Enterprise Testing Conditions & Specifications
| Enterprise Testing Conditions | |
| Threat Prevention (Gbps) | 15 |
| NGFW (Gbps) | 27 |
| IPS Throughput (Gbps) | 28.8 |
| Firewall Throughput (Gbps) | 78.3 |
| RFC 3511, 2544, 2647, 1242 Performance (LAB) | |
| Firewall 1518B UDP (Gbps) | 159 |
| VPN AES-128 (Gbps) | 20 |
| Connections per Second | 435,000 |
| Concurrent Connections | 8/16/32M |
| Additional Features & Highlights | 2x CPUs, 24 physical cores, 48 virtual cores 1x 480GB SSD (2x in Plus) 1x AC power supplies (2x in Plus, DC option) 48, 64 GB, 128 GB memory options Lights-Out-Management card (optional) Virtual Systems (Base/Plus/max mem): 60/250/250 |
| Network Expansion Slot Options | 8x 10/100/1000Base-T RJ45 port card, up to 34 ports 4x 1000Base-F SFP port card, up to 16 ports 4x 10GBase-F SFP+ port card, up to 16 ports 2x 40G QSFP+ port card, up to 8 ports 2x 100/25G QSFP28 port card, up to 8 ports |
| Content Security – First Time Prevention | CPU-level, OS-level and static file analysis File disarm and reconstruction via Threat Extraction Average emulation time for unknown files: under 100 seconds Maximal file size for Emulation: 100 MB Emulation OS Support: Windows XP, 7, 8.1, 10 |
| Applications | Use 8,000+ pre-defined or customize your own applications Accept, prevent, schedule, and apply traffic-shaping |
| Data Loss Prevention | Classify 700+ pre-defined data types End user and data owner incident handling |
| Dynamic User-based Policy | Integrates with Microsoft AD, LDAP, RADIUS, Cisco pxGrid, Terminal Servers and 3rd parties via Web API Support: Windows, macOS, Linux, Android, Apple iOS |
| Network Connectivity | Physical and virtual interfaces: 1024/4096 802.3ad passive and active link aggregation Layer 2 (transparent) and Layer 3 (routing) mode |
| High Availability | Active/Active L2, Active/Passive L2 and L3 Session failover for routing change, device and link failure ClusterXL or VRRP |
| IPv6 | NAT66, NAT64, NAT46 CoreXL, SecureXL, HA with VRRPv3 Unicast and Multicast Routing |
| Routing Protocols | OSPFv2 and v3, BGP, RIP Static routes, Multicast routes Policy-based routing PIM-SM, PIM-SSM, PIM-DM, IGMP v2, and v3 |
| Power Requirements | Single Power Supply rating: 1300W AC input: 100 to 240V (47-63Hz), 40~-72VDC Power consumption avg/max: 261W/307W Maximum thermal output AC: 1048 BTU/hr |
| Dimensions & Weight | Enclosure: 2RU Dimensions: 17.4 x 24 x 3.5 in. (442 x 610 x 88mm) Weight: 39.7 lbs. (18 kg) |
| Environmental Conditions | Operating: 0° to 40°C, humidity 5% to 95% Storage: –20° to 70°C, humidity 5% to 95% @ 60°C |
| Certifications | Safety: UL, CB, CE, TUV GS Emissions: FCC, CE, VCCI, RCM/C-Tick Environmental: RoHS, WEEE, REACH, ISO14001 |
