Thông số kỹ thuật
Enterprise Firewall Specifications
| Enterprise Testing Conditions | Value |
| Threat Prevention (Gbps) | 15 |
| NGFW (Gbps) | 27 |
| IPS Throughput (Gbps) | 28.8 |
| Firewall Throughput (Gbps) | 78.3 |
| RFC 3511, 2544, 2647, 1242 Performance (LAB) | Value |
| Firewall 1518B UDP (Gbps) | 159 |
| VPN AES-128 (Gbps) | 20 |
| Connections per Second | 435,000 |
| Concurrent Connections | 8/16/32M |
| Hardware Highlights | Details |
| Processor | 2x CPUs, 24 physical cores, 48 virtual cores |
| Storage | 1x 480GB SSD (2x in Plus) |
| Power Supplies | 1x AC power supplies (2x in Plus, DC option) |
| Memory Options | 48, 64 GB, 128 GB |
| Management | Lights-Out-Management card (optional) |
| Virtual Systems | Base/Plus/max mem: 60/250/250 |
| Network Expansion Slot Options | Specifications |
| RJ45 Port Cards | 8x 10/100/1000Base-T, up to 34 ports |
| SFP Port Cards | 4x 1000Base-F, up to 16 ports |
| SFP+ Port Cards | 4x 10GBase-F, up to 16 ports |
| QSFP+ Port Cards | 2x 40G, up to 8 ports |
| QSFP28 Port Cards | 2x 100/25G, up to 8 ports |
| Content Security | Capabilities |
| First Time Prevention | CPU-level, OS-level & static file analysis File disarm & reconstruction via Threat Extraction Emulation time: under 100 seconds Max file size: 100 MB OS Support: Windows XP, 7, 8.1, 10 |
| Applications | 8,000+ pre-defined or custom applications; Accept, prevent, schedule, traffic-shaping |
| Data Loss Prevention | Classify 700+ pre-defined data types; End user & data owner incident handling |
| Dynamic User Policy | AD, LDAP, RADIUS, Cisco pxGrid, Terminal Servers integration Support: Windows, macOS, Linux, Android, iOS |
| Network Features | Details |
| Network Connectivity | Total physical/virtual interfaces: 1024/4096 802.3ad link aggregation (passive & active) Layer 2 (transparent) & Layer 3 (routing) mode |
| High Availability | Active/Active L2, Active/Passive L2 & L3 Session failover for routing, device & link failure ClusterXL or VRRP |
| IPv6 Support | NAT66, NAT64, NAT46; CoreXL, SecureXL, HA with VRRPv3 |
| Routing Protocols | OSPFv2 & v3, BGP, RIP Static & Multicast routes Policy-based routing PIM-SM, PIM-SSM, PIM-DM, IGMP v2 & v3 |
| Power Requirements | Specifications |
| Power Supply Rating | 1300W |
| AC Input | 100 to 240V (47-63Hz), 40~-72VDC |
| Power Consumption | Average/Max: 261W/307W |
| Thermal Output | 1048 BTU/hr |
| Physical Specifications | Details |
| Enclosure | 2RU |
| Dimensions (W x D x H) | 17.4 x 24 x 3.5 in. (442 x 610 x 88mm) |
| Weight | 39.7 lbs. (18 kg) |
| Environmental Conditions | Range |
| Operating | 0° to 40°C, humidity 5% to 95% |
| Storage | –20° to 70°C, humidity 5% to 95% @ 60°C |
| Certifications | Standards |
| Safety | UL, CB, CE, TUV GS |
| Emissions | FCC, CE, VCCI, RCM/C-Tick |
| Environmental | RoHS, WEEE, REACH, ISO14001 |
