Thông số kỹ thuật
| Performance | |
|---|---|
| Enterprise Test Conditions | Threat Prevention: 15 Gbps NGFW: 27 Gbps IPS: 28.8 Gbps Firewall: 78.3 Gbps |
| RFC 3511, 2544, 2647, 1242 PERFORMANCE (LAB) | Firewall 1518B UDP: 159 Gbps VPN AES-128: 20 Gbps Connections/sec: 435,000 Concurrent connections: 8/16/32M |
| Additional Features | |
|---|---|
| Highlights | 1x CPU, 24 physical cores, 48 virtual cores 1x 480GB SSD (2x in Plus) 1x AC power supplies (2x in Plus, DC option) 48, 64, 128 GB memory options Lights-Out-Management card (optional in Base package) Virtual Systems (Base/Plus/max mem): 60/250/250 |
| Network Expansion Slot Options (3 of 4 slots open) | 8x 10/100/1000Base-T RJ45 port card, up to 34 ports 4x 1000Base-F SFP port card, up to 16 ports 4x 10GBase-F SFP+ port card, up to 16 ports 2x 40GBase-F QSFP+ port card, up to 8 ports 2x 100/25G QSFP28 port card, up to 8 ports |
| Content Security | |
|---|---|
| First Time Prevention Capabilities | CPU-level, OS-level and static file analysis File disarm and reconstruction via Threat Extraction Average emulation time for unknown files under 100 seconds Max file size for Emulation is 100 MB Emulation OS Support: Windows XP, 7, 8.1, 10 |
| Applications | Use 8,000+ pre-defined or customize your own applications Accept, prevent, schedule, and apply traffic-shaping |
| Data Loss Prevention | Classify 700+ pre-defined data types End user and data owner incident handling |
| Dynamic User-based Policy | Integrates with Microsoft AD, LDAP, RADIUS, Cisco pxGrid, Terminal Servers and 3rd parties via Web API Enforce consistent policy for local and remote users on Windows, macOS, Linux, Android and Apple iOS platforms |
| Network | |
|---|---|
| Network Connectivity | Total physical and virtual (VLAN) interfaces per appliance: 1024/4096 (single gateway/with virtual systems) 802.3ad passive and active link aggregation Layer 2 (transparent) and Layer 3 (routing) mode |
| High Availability | Active/Active L2, Active/Passive L2 and L3 Session failover for routing change, device and link failure ClusterXL or VRRP |
| IPv6 | NAT66, NAT64, NAT46 CoreXL, SecureXL, HA with VRRPv3 |
| Unicast and Multicast Routing (see SK98226) | OSPFv2 and v3, BGP, RIP Static routes, Multicast routes Policy-based routing PIM-SM, PIM-SSM, PIM-DM, IGMP v2, and v3 |
| Physical | |
|---|---|
| Power Requirements | Single Power Supply rating: 1300W Power input: 100 to 240V (47-63Hz), 40~-72VDC Power consumption avg/max: AC 261W/307W Maximum thermal output AC: 1048 BTU/hr |
| Dimensions | Enclosure: 2RU Dimensions (WxDxH): 17.4 x 24 x 3.5 in. (442 x 610 x 88mm) Weight (Base/Plus): 39.7 lbs. (18 kg) |
| Environmental Conditions | Operating: 0° to 40°C, humidity 5% to 95% Storage: –20° to 70°C, humidity 5% to 95% at 60°C |
| Certifications | Safety: UL, CB, CE, TUV GS Emissions: FCC, CE, VCCI, RCM/C-Tick Environmental: RoHS, WEEE, REACH1, ISO14001 |
