Thông số kỹ thuật
| Performance | |
|---|---|
| Enterprise Test Conditions | Threat Prevention: 17.6 Gbps NGFW: 6.6 Gbps IPS: 9.1 Gbps Firewall: 42 Gbps |
| RFC 3511, 2544, 2647, 1242 PERFORMANCE (LAB) | Firewall 1518B UDP: 171 Gbps VPN AES-128: 19 Gbps Concurrent connections: 25M |
| Additional Features | |
|---|---|
| 4x 100 GbE QSFP28 ports | 2x CPU, 16 physical cores, 32 virtual cores 1x AC power supply 1x system fan 1x optional spare power supply 1x optional PCIe x8 expansion slot 4x 40G QSFP+ ports |
| Content Security | |
|---|---|
| Real Time Prevention Capabilities | CPU-based, OS-level real-time file analysis Real-time sandbox file scan via Threat Emulation SandBlast file scan for unknown threats, analysis file handling up to 100 files/second Emulation OS Support: Windows XP, 7, 8, 10 |
| Applications | Fine-grained application control, web app protection |
| Data Loss Prevention | Classify, Stop pre-defined data types |
| Dynamic User-based Policy | Integrates with Microsoft AD, LDAP, RADIUS, Cisco pxGrid, Terminal Servers; multi-OS support (Windows, Mac, Linux, Android) |
| Network | |
|---|---|
| Network Connectivity | Total physical and virtual (VLAN) interfaces per appliance: 1024/4096 (single gateway/with virtual systems) 802.3ad passive and active link aggregation; Layer 2 (transparent) and Layer 3 (routing) mode |
| High Availability | Active/Active L2, Active/Passive L2 and L3 Session failover for routing change, device and link failure ClusterXL or VRRP |
| IPv6 | NAT64, CoreXL, SecureXL |
| Unicast and Multicast Routing (see SK98226) | OSPFv2 and v3, BGP, RIP Static routes, multicast routes Policy-based routing PIM-SM, PIM-SSM, PIM-DM, IGMP v2, v3 |
| Macro | |
|---|---|
| Maximums | Up to 8 Security Groups Up to 19 gateways in a Security Group Up to 150 gateways in all Security Groups (Active/standby, 1:1 hot-standby, Total switching 175G) |
| Physical | |
|---|---|
| Power Requirements | Single Power Supply rating: AC 100~240V, 4~2A, 50/60Hz Power consumption: 480W Average/Max operating: 416W/848W |
| Dimensions | Enclosure: 2RU Dimensions: 448 (W) x 448 (D) x 89 (H) mm Weight: 19 kg |
| Environmental Conditions | Operating: 0° to 40°C, humidity 10 to 95% Storage: –20° to 70°C, humidity 5 to 95% |
| Certifications | UL, CE, FCC, VCCI, Environmental RoHS, WEEE, Reach, ISO14001 |
