Thông số kỹ thuật
| Performance | |
|---|---|
| Enterprise Test Conditions | Threat Prevention: 780 Mbps NGFW: 1.5 Gbps IPS: 1.99 Gbps Firewall: 3.3 Gbps |
| RFC 3511, 2544, 2647, 1242 PERFORMANCE (LAB) | Firewall 1518B UDP: 4 Gbps VPN AES-128: 2.71 Gbps Connections/sec: 32,000 Concurrent connections: 2M |
| Additional Features | |
|---|---|
| Highlights | 1x CPU, 4 physical cores 1x 240 GB SSD storage 8 GB memory Virtual Systems (maximum): 5 |
| Content Security | |
|---|---|
| First Time Prevention Capabilities | CPU-level, OS-level and static file analysis File disarm and reconstruction via Threat Extraction Average emulation time for unknown files: under 100 seconds Maximal file size for Emulation: 100 MB Emulation OS Support: Windows XP, 7, 8.1, 10 |
| Applications | Use 8,000+ pre-defined or customize your own applications Accept, prevent, schedule, and apply traffic-shaping |
| Data Loss Prevention | Classify 700+ pre-defined data types End user and data owner incident handling |
| Dynamic User-based Policy | Integrates with Microsoft AD, LDAP, RADIUS, Cisco pxGrid, Terminal Servers and with 3rd parties via a Web API Enforce consistent policy for local and remote users on Windows, macOS, Linux, Android and Apple iOS platforms |
| Network | |
|---|---|
| Network Connectivity | Total physical and virtual (VLAN) interfaces per appliance: 1024/4096 802.3ad passive and active link aggregation Layer 2 (transparent) and Layer 3 (routing) mode |
| High Availability | Active/Active L2, Active/Passive L2 and L3 Session failover for routing change, device and link failure ClusterXL or VRRP |
| IPv6 | NAT66, NAT64, NAT46 CoreXL, SecureXL, HA with VRRPv3 |
| Unicast and Multicast Routing (see SK98226) | OSPFv2 and v3, BGP, RIP Static routes, Multicast routes Policy-based routing PIM-SM, PIM-SSM, PIM-DM, IGMP v2, and v3 |
| Physical | |
|---|---|
| Power Requirements | Single Power Supply rating: 40W AC power input: 100 to 240V (50-60Hz) Power consumption max: 24.2W Maximum thermal output: 82.6 BTU/hr |
| Dimensions | Enclosure: Desktop Dimensions (WxDxH): 8.3 x 8.3 x 1.65 in. (210 x 210 x 42mm) Weight: 3.1 lbs. (1.4 kg) |
| Environmental Conditions | Operating: 0° to 40°C, humidity 95% Storage: –20° to 70°C, humidity 95% |
| Certifications | Safety: UL, CB, CE, TUV GS Emissions: FCC, CE, VCCI, RCM/C-Tick Environmental: RoHS, WEEE, REACH1, ISO14001 |
