| Enterprise Testing Conditions CPAP-SG1575RWTEL-4L-SNBT-DC |
| Threat Prevention (Mbps) |
280 |
| Next Generation Firewall (Mbps) |
700 |
| IPS Throughput (Mbps) |
960 |
| Firewall Throughput (Mbps) |
1,300 |
| Firewall 1518 Byte UDP Packets (Mbps) |
3,900 |
| VPN AES-128 Throughput (Mbps) |
1,300 |
| Connections per Second |
10,500 |
| Concurrent Connections |
500,000 |
| Software |
| Security |
Firewall, VPN, User Awareness, QoS, Application Control, URL Filtering, IPS, Anti-Bot, Antivirus, SandBlast Threat Emulation |
| Unicast, Multicast Routing and Clustering |
OSPFv2, BGPv4+, RIP, PIM, ClusterXL High Availability |
| IPv6 Support |
Local network and internet connectivity, dual stack handling |
| Mobile Access License (Users) |
200 remote SNX or Mobile VPN client users |
| Protocols |
Over IP protocols, including VoIP, Secure CIP, SIP, E.164, DHCP |
| Hardware |
| WAN Port |
1x 10/100/1000Base-T RJ-45; 1x 1000BaseF SFP |
| DMZ Port |
1x 10/100/1000Base-T RJ-45; 1x 1000BaseF SFP |
| LAN Ports |
5x 10/100/1000Base-T RJ-45 ports |
| Wi-Fi (optional) |
802.11 b/g/n/ac MIMO 3×3 (max 1,200 Mbps) |
| Radio Band |
One radio band, 2.4GHz or 5GHz (max 450/1300 Mbps) |
| 3G/4G/LTE (optional) |
Embedded modem, CAT6 with antenna |
| Console Port |
1x USB-C |
| USB Port |
1x USB 3.0 |
| SIM Card Slot |
Dual SIM slot (Nano or Micro) |
| SD Card Slot |
Micro-SD slot (max 64GB); 5G/2G support |
| Dimensions |
| Enclosure |
Desktop, wall mount, DIN rail |
| Dimensions (W x D x H) |
150 x 120 x 45 mm, 5.9 x 4.7 x 1.8 in |
| Weight |
0.4 kg (0.88 lbs) |
| Environment |
| Operating Temperature |
