| Enterprise Testing Conditions |
| Threat Prevention (Mbps) |
860 |
| Next Generation Firewall (Mbps) |
1,300 |
| IPS Throughput (Mbps) |
1,400 |
| Firewall Throughput (Mbps) |
2,800 |
| RFC 3511, 2544, 2647, 1242 Performance (LAB) |
| Firewall 1518 Byte UDP Packets (Mbps) |
6,400 |
| VPN AES-128 Throughput (Mbps) |
2,600 |
| Connections per Second |
21,000 |
| Concurrent Connections |
500,000 |
| Software |
| Security |
Firewall, VPN, User Aware, QoS, Application Control, URLF, IPS, Anti-Bot, Antivirus, Anti-Spam, sandboxing |
| Unicast, Multicast Routing |
OSPFv2, BGPv4 and 4++, RIP, PIM (SM, DM, SSM), IGMP |
| Mobile Access License (Users) |
200 remote SNX or Mobile VPN client users |
| Hardware |
| WAN Port |
1x 10/100/1000Base-T RJ-45 port |
| DMZ Port |
1x 10/100/1000Base-T RJ-45 / 1x 1000BaseF SFP port (transceiver not included) |
| LAN Ports |
8x 10/100/1000Base-T RJ-45 ports |
| Console Port |
1x USB-C |
| USB Port |
1x USB 3.0 |
| SD Card Slot |
Micro-SD slot |
| Dimensions |
| Enclosure |
Desktop |
| Dimensions (W x D x H) |
210 x 170 x 42 mm, 8.3 x 6.7 x 1.7 in |
| Weight |
0.87 kg (1.9 lbs) |
| Environment |
| Operating / Storage |
0°C – 40°C / -45°C – 60°C (5–95%, non-condensing) |
| Power Requirements |
| AC Input |
110 – 240VAC, 50 – 60 Hz |
| Power Supply Rating |
12V/3.3A 40W power adapter |
| Power Consumption (Max) |
26.01W |
| Heat Dissipation |
88.75 |
