| Enterprise Testing Conditions |
| Threat Prevention (Mbps) |
1,500 |
| Next Generation Firewall (Mbps) |
3,200 |
| IPS Throughput (Mbps) |
3,800 |
| Firewall Throughput (Mbps) |
4,800 |
| RFC 3511, 2544, 2647, 1242 Performance (LAB) |
| Firewall 1518 Byte UDP Packets (Mbps) |
8,000 |
| VPN AES-128 Throughput (Mbps) |
3,200 |
| Connections per Second |
55,000 |
| Concurrent Connections |
2,400,000 |
| Software |
| Security |
Firewall, VPN, User Awareness, QoS, Application Control, URL Filtering, IPS, Anti-Bot, Antivirus, Anti-Spam and SandBlast Threat Emulation (sandboxing) |
| Unicast, Multicast Routing |
OSPFv2, BGPv4 and 4++, RIP, IGMP |
| Mobile Access License (Users) |
500 remote SNX or Mobile VPN client users |
| Hardware |
| WAN Port |
1x 10/100/1000Base-T RJ-45 / 1000BaseF SFP port (transceiver not included) |
| DMZ Port |
1x 10/100/1000Base-T RJ-45 / 1000BaseF SFP port (transceiver not included) |
| LAN Ports |
16x 10/100/1000Base-T RJ-45 ports |
| Console Port |
1x USB-C and 1x RJ-45 console port |
| USB Port |
2x USB 3.0 ports |
| Storage |
Micro-SD card slot with 32 and 64 GB card options |
| eMMC |
32 GB |
| MTBF |
22.26 years @ 25°C |
| Dimensions |
| Enclosure |
1U |
| Dimensions (W x D x H) |
430 x 300 x 44.2 mm (16.93 x 11.8 x 1.74 in.) |
| Weight |
6.17 kg (13.6 lbs) |
| Environment |
| Operating / Storage |
0°C – 40°C / -45°C – 60°C (5-95%, non-condensing) |
| Power Requirements |
| AC Input |
110 – 240VAC, 50 – 60 Hz |
| Power Supply |
single 150W power supply |
| Power Consumption (Max) |
71.6W |
| Heat Dissipation |
244.31 |
