| Series |
MS120 |
| Deployment type |
Compact |
| Interface |
- 24 x 10/100/1000BASE-T Ethernet RJ45 with auto negotiation and crossover detection (auto-MDIX crossover)
- 4 x 1G SFP uplink
- RJ45 Management port
|
| Switching Capacity |
56 Gbps |
| Forwarding rate |
41.67mpps |
| Jumbo frame support |
9578 byte ethernet frame |
| Power configuration |
Fixed internal |
| Power Supply/Model Number |
Power input: 100 – 240 VAC, 47-63 Hz |
| Idle / Full Load Power |
8 / 18 W |
| Routing capabilities |
DHCP Relay |
| Physical Dimensions (H x W x D) |
1.73 x 17.32 x 9.84” (4.40 x 44 x 25cm) |
| Weight |
8.09 lb (3.67 kg) |
| Environment |
- Operating temperature: 0°C to 45°C
- Humidity: 5 to 95% non-condensing
- Fanless operation
|
| MTBF |
707,873 |
| Regulatory |
- CSA-US (US, Canada)
- FCC (USA)
- IC (Canada)
- CE (Europe)
- RCM (Australia/New Zealand)
- RoHS
|
