| Series |
MS120 |
| Deployment type |
Compact |
| Interface |
- 48 × 10/100/1000BASE-T Ethernet RJ45 PoE+ 740W with auto negotiation and crossover detection (auto-MDIX crossover)
- 4 × 1G SFP uplink
- RJ45 Management port
|
| Switching Capacity |
104 Gbps |
| Forwarding rate |
77.38 mpps |
| Jumbo frame support |
9578 byte ethernet frame |
| Power configuration |
Fixed internal |
| Power Supply/Model Number |
Power input: 100 – 240 VAC, 47-63 Hz |
| Idle / Full Load Power |
37 / 908 W |
| Routing capabilities |
DHCP Relay |
| Physical Dimensions (H x W x D) |
1.73” x 17.32” x 13.39” (4.40 x 44 x 34cm) |
| Weight |
12.70 lb (5.70 kg) |
| Environment |
- Operating temperature: 0°C to 45°C
- Humidity: 5 to 95% non-condensing
- Fanless operation
|
| MTBF |
660,538 |
| Regulatory |
- CSA-US (US, Canada)
- FCC (USA)
- IC (Canada)
- CE (Europe)
- RCM (Australia/New Zealand)
- RoHS
|
