| Interfaces |
- 24 × 10/100/1000BASE-T Ethernet (RJ45)
- 4 × 10G SFP+ ports for uplinks
- Auto-negotiation and crossover detection
|
| Management |
- Managed via the Web with the Meraki cloud management platform
- Integrated with Meraki wireless and complete portfolio of IT solutions
- Zero-touch remote provisioning (no staging needed)
- Detailed historical per-port and per-client usage statistics
- Operating system, device, and hostname fingerprinting
- SNMP and SYSLOG support for integration
- Automatic firmware upgrades with scheduling control
|
| Remote Diagnostics |
- Email, SMS, and mobile push notification alerts
- Ping, traceroute, cable testing, and link failure detection with alerting
- Remote packet capture
- Dynamic and interactive network discovery and topology
- Combined event and configuration change logs with instant search
|
| Stacking |
- Virtual Stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configuration
|
| Ethernet Switching Capabilities |
- 802.1p Quality of Service, 8 queues (w/ 6 configurable for DSCP-to-CoS mapping)
- 802.1Q VLAN and trunking support for up to 4,094 VLANs
- 802.1w, 802.1D Rapid Spanning Tree Protocol (RSTP, STP)
- STP Enhancements: BPDU guard, Root guard, Loop guard, UDLD
- 802.1ab LLDP and CDP
- 802.3ad Link aggregation (up to 8 ports per aggregate, multichassis support)
- Port mirroring
- IGMP snooping for multicast filtering
- MAC forwarding entries: 16K
|
| Security |
- Integrated multi-factor authentication for cloud management
- Role-based access control (RBAC)
- Corporate-wide password policy enforcement
- IEEE 802.1X RADIUS and MAB, hybrid authentication, RADIUS server testing
- Single-Host/Multi-Domain/Multi-Host/Multi Authentication
- Port security: Sticky MAC, MAC whitelisting
- DHCP snooping, detection and blocking
- IPv4 and IPv6 ACLs
|
| Performance |
- Switching capacity: 128 Gbps
- Forwarding rate: 95.23 mpps
- Jumbo frame support (9578 byte Ethernet frame)
- Flow control
|
| Layer 3 |
|
| Power |
- Power input: 100-240V~, 50-60Hz
- MS125-24: 10.3-25.6 W max, fanless
- MS125-24P: 25-426.1 W
|
| Mounting |
- 1U Rack-mountable with included rack mount hardware
- 2-post front mounting options available
|
| Environment |
- Operating temperature: 0°C to 45°C
- 0°C – 40°C at sea level
- 0°C – 35°C at 10,000 feet for MS125-24 when using MA-SFP-10GB-ER
- Humidity: 5 to 95% RH
|
| Regulatory |
- CSA-US (US, Canada)
- FCC (USA)
- IC (Canada)
- CE (Europe)
- RCM (Australia/New Zealand)
- RoHS
- Contact sales@meraki.com for international availability
|
| Warranty |
- Full lifetime hardware warranty, next-day advanced replacement included
|
| MTBF at 25°C |
- MS125-24-HW: 1,957,381
- MS125-24P-HW: 294,713
|
| Physical Specifications (H × W × D) |
- MS125-24-HW: 1.73” × 17.32” × 9.84” (4.40 × 44 × 25cm), 8.15 lb (3.70 kg)
- MS125-24P-HW: 1.73” × 17.32” × 9.84” (4.40 × 44 × 25cm), 9.25 lb (4.20 kg)
|
