| Recommended use case |
Medium to large branch with up to 500 users |
| NGFW throughput |
2.5 Gbps |
| Advanced security services throughput*1.5 |
2.5 Gbps |
| Maximum site-to-site VPN throughput |
2.5 Gbps |
| Maximum site-to-site VPN tunnels*25 |
500 |
| WAN interfaces (dedicated) |
2x 10 GBE SFP+ + 2x 2.5 GBE RJ45 (1x PoE+) |
| LAN interfaces (fixed) |
4x GBE RJ45 + 2x 10 GBE SFP+ |
| Mounting |
1U rack |
| Dimensions (w x d x h) |
19.08 in x 11.23 in x 1.73 in (484.8 mm x 285.2 mm x 44 mm) |
| Weight |
8.99 lb (3.17 kg) |
| Power supply |
Internal 100-127 V, 100-240 V (50/60 Hz) |
| Power load (idle/max) |
42 W/91 W |
| Operating temperature |
32 °F to 104 °F (0 °C to 40 °C) |
| Humidity |
5% to 95% |
