| Datasheet FortiGate FG-600F-BDL-950-12 |
| Interfaces and Modules |
| Hardware Accelerated GE RJ45 Interfaces |
16 |
| Hardware Accelerated GE SFP Slots |
8 |
| Hardware Accelerated 10GE SFP+ Slots |
4 |
| Hardware Accelerated 25GE SFP28 / 10GE SFP+ / GE SFP Ultra Low Latency Slots |
4 |
| GE RJ45 MGMT/HA Ports |
2 |
| USB Port |
2 |
| RJ45 Console Port |
1 |
| Onboard Storage |
0 |
| Included Transceivers |
2x SFP (SX 1 GE) |
| System Performance — Enterprise Traffic Mix |
| IPS Throughput |
14 Gbps |
| NGFW Throughput |
11.5 Gbps |
| Threat Protection Throughput |
10.5 Gbps |
| System Performance and Capacity |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
139 / 137.5 / 70 Gbps |
| IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
139 / 137.5 / 70 Gbps |
| Firewall Latency (64 byte, UDP) |
4.12 μs |
| Firewall Throughput (Packets Per Second) |
105 Mpps |
| Concurrent Sessions (TCP) |
7.8 Million |
| New Sessions/Second (TCP) |
550,000 |
| Firewall Policies |
10,000 |
| IPsec VPN Throughput (512 byte) |
55 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
2,000 |
| Client-to-Gateway IPsec VPN Tunnels |
50,000 |
| SSL-VPN Throughput |
4.3 Gbps |
| Concurrent SSL-VPN Users (Recommended Max, Tunnel Mode) |
2,500 |
| SSL Inspection Throughput (IPS, avg. HTTPS) |
9 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) |
7,500 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
840,000 |
| Application Control Throughput (HTTP 64K) |
32 Gbps |
| CAPWAP Throughput (HTTP 64K) |
TBA |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of FortiSwitches Supported |
96 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) |
1024 / 512 |
| Maximum Number of FortiTokens |
5,000 |
| High Availability Configurations |
Active / Active, Active / Passive, Clustering |
| Dimensions |
| Height x Width x Length (inches) |
1.75 x 17.0 x 15.0 |
| Height x Width x Length (mm) |
44.45 x 432 x 380 |
| Weight |
15.6 lbs (7.1 kg) |
| Form Factor |
Rack Mount, 1 RU |
| AC Power Consumption (Average / Maximum) |
169 W / 255 W |
| AC Power Input |
100–240V AC, 50/60Hz |
| AC Current (Maximum) |
6A@100V |
| Heat Dissipation |
871 BTU/h |
| Redundant Power Supplies (Hot Swappable) |
Yes |
| Operating Environment and Certifications |
| Operating Temperature |
32–104°F (0–40°C) |
| Storage Temperature |
-31–158°F (-35–70°C) |
| Humidity |
5–90% non-condensing |
| Noise Level |
55 dBA |
| Airflow |
Side and Front to Back |
| Operating Altitude |
Up to 7,400 ft (2,250 m) |
| Compliance |
FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB |
| Certifications |
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN, USGv6/IPv6 |
