| I/O Ports and Slots |
- 24 RJ-45 autosensing 10/100/1000 ports
- (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
- Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
- 2 SFP 1GbE ports
|
| Physical Characteristics |
- Dimensions: 215.9(d) x 443.0(w) x 43.9(h) mm
- Weight: 5.50 lb (2.49 kg)
|
| Memory and Flash |
ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash, packet buffer: 1.5 MB |
| Performance |
- Throughput: 38.68 Mpps
- Switching capacity: 52 Gbps
- 100 Mb latency: < 5.2 uSec
- 1000 Mb latency: < 2.8 uSec
- MAC address table: 16,000 entries
- Reliability MTBF: 203.6 years
|
| Environment |
- Operating temperature: 32°F to 104°F (0°C to 40°C)
- Operating relative humidity: 15% to 95% @ 104°F (40°C)
- Nonoperating/storage temperature: -40°F to 158°F (-40°C to 70°C)
- Nonoperating/storage relative humidity: 15% to 95% @ 140°F (60°C)
- Altitude: up to 10,000 ft (3 km)
|
| Acoustics |
- Idle: Fanless
- 100% traffic: Fanless
- 100% traffic / 0% PoE: Fanless
- 100% traffic / 50% PoE: Fanless
- 100% traffic / 100% PoE: Fanless
|
| Electrical Characteristics |
- Frequency: 50Hz/60Hz
- AC voltage: 100-127VAC / 200-240VAC
- Current: 1.0A / 0.5A
- Maximum power rating: 100-127V: 86.07W, 200-220V: 83.67W
- Idle power: 100-127V: 8.3W, 200-220V: 8.2W
- PoE power: –
- Power supply: Internal power supply
|
| Safety |
- EN/IEC 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
- EN/IEC 62368-1, 2nd. & 3rd. Ed.
- UL 62368-1, 2nd. & 3rd. Ed.
- CAN/CSA C22.2 No. 62368-1, 2nd. & 3rd. Ed.
- EN/IEC 60825-1:2014 Class 1
|
| Emissions |
- EN 55032:2015/CISPR 32, Class A
- FCC CFR 47 Part 15: 2018 Class A
- ICES-003 Class A, VCCI Class A, CNS 13438 Class A, KN 32 Class A, AS/NZS CISPR 32 Class A
|
| Immunity |
- Generic: EN 55035, CISPR 35, KN35
- EN: EN 55035, CISPR 35
- ESD: EN/IEC 61000-4-2
- Radiated: EN/IEC 61000-4-3
- EFT/Burst: EN/IEC 61000-4-4
- Surge: EN/IEC 61000-4-5
- Conducted: EN/IEC 61000-4-6
- Power frequency magnetic field: EN/IEC 61000-4-8
- Voltage dips and interruptions: EN/IEC 61000-4-11
- Harmonics: EN/IEC 61000-3-2
- Flicker: EN/IEC 61000-3-3
|
| Device Management |
- Aruba Instant On Cloud
- Web browser
- SNMP Manager
|
| Mounting |
- Mounts in EIA-standard 19 in. telco rack or equipment cabinet (2-post rack kit included)
- Supports table-top mounting
- Supports rack-mounting
- Supports wall-mounting with ports facing up or down
- Supports under-table mounting using the brackets provided
- Must be mounted top surface up. Do not mount upside-down to preserve reliability
|
