| I/O ports and slots |
- 24 RJ-45 autosensing 10/100/1000 ports IEEE 802.3at Class 4 PoE (ports 1-12)
- (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
- Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
- 2 SFP 1GbE ports
|
| Physical characteristics |
- Dimensions (D x W x H): 25.3 x 44.3 x 4.39 cm
- Weight: 3.47 kg
|
| Processor and memory |
ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash, packet buffer: 1.5MB |
| Performance |
- 100 Mb latency: < 5.2 uSec
- 1000 Mb latency: < 2.8 uSec
- 10000 Mb latency: n/a
- Throughput: 38.68 Mpps
- Capacity: 52 Gbps
- MAC address table: 16,000 entries
- Reliability MTBF: 96.6 years
|
| Environment |
- Operating temperature: 0°C to 40°C
- Operating relative humidity: 15% to 95% @ 40°C
- Nonoperating/storage temperature: -40°C to 70°C
- Nonoperating/storage relative humidity: 15% to 95% @ 60°C
- Altitude: up to 3 km
|
| Acoustics |
Fanless |
| Electrical characteristics |
- Frequency: 50Hz/60Hz
- AC voltage: 100-127VAC / 200-240VAC
- Current: 2.7A / 1.4A
- Maximum power rating: 100-127V: 244.6W; 200-220V: 237.2W
- Idle power: 100-127V: 14.5W; 200-220V: 13.4W
- PoE power: 195 W Class 4 PoE
- Power supply: Internal power supply
|
| Device management |
- Instant On Cloud
- Web browser
- SNMP Manager
|
| Mounting positions and supported racking |
- Mounts in an EIA standard 19 in. telco rack or equipment cabinet. 2-post rack kit included
- Supports table-top mounting
- Supports rack-mounting
- Supports wall-mounting with ports facing either up or down
- Supports under-table mounting using the brackets provided
|
