| I/O Ports and Slots |
| Number of Ports |
8 RJ-45 autosensing 10/100/1000 ports |
| PoE Standard |
IEEE 802.3at Class 4 PoE (ports 1-4) |
| Supported Ethernet Standards |
IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T |
| Duplex Modes |
10/100 Mbps: half or full; 1000 Mbps: full only |
| Physical Characteristics |
| Dimensions |
195.1(d) x 245.1(w) x 43.9(h) mm |
| Weight |
3.40 lb (1.54 kg) |
| Memory and Flash |
| Processor |
ARM Cortex-A9 @ 800MHz |
| RAM |
512 MB SDRAM |
| Flash Memory |
256 MB |
| Packet Buffer |
1.5 MB |
| Performance |
| Throughput |
11.90 Mpps |
| Switching Capacity |
16 Gbps |
| Latency at 100 Mbps |
< 5.2 µSec |
| Latency at 1000 Mbps |
< 2.8 µSec |
| MAC Address Table Size |
8,000 entries |
| Reliability (MTBF) |
105.9 years |
| Environment |
| Operating Temperature |
32°F to 104°F (0°C to 40°C) |
| Operating Humidity |
15% to 95% @ 104°F (40°C) |
| Non-operating Temperature |
-40°F to 158°F (-40°C to 70°C) |
| Non-operating Humidity |
15% to 95% @ 140°F (60°C) |
| Maximum Altitude |
Up to 10,000 ft (3 km) |
| Acoustics |
| Idle to 100% Traffic (with/without PoE) |
Fanless |
| Electrical Characteristics |
| Frequency |
50Hz/60Hz |
| AC Voltage |
100-127VAC / 200-240VAC |
| Current |
1.0A / 0.5A |
| Maximum Power Rating |
86.07W (100-127V), 83.67W (200-220V) |
| Idle Power |
8.3W (100-127V), 8.2W (200-220V) |
| PoE Power |
65W Class 4 PoE |
| Power Supply |
Internal |
| Safety Standards |
| EN/IEC 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, EN/IEC 62368-1 (2nd & 3rd Ed.), UL 62368-1 (2nd & 3rd Ed.), CAN/CSA C22.2 No. 62368-1 (2nd & 3rd Ed.), EN/IEC 60825-1:2014 Class 1 |
| Emissions and Immunity |
| Emissions |
EN 55032:2015/CISPR 32 Class A, FCC CFR 47 Part 15:2018 Class A, ICES-003 Class A, VCCI Class A, CNS 13438 Class A, KN 32 Class A, AS/NZS CISPR 32 Class A |
| Immunity |
EN 55035, CISPR 35, KN35 |
| ESD & Other Tests |
EN/IEC 61000 series (4-2, 4-3, 4-4, 4-5, 4-6, 4-8, 4-11, 3-2, 3-3) |
| Device Management |
| Management Options |
Aruba Instant On Cloud; Web browser; SNMP Manager |
| Mounting |
| Rack Options |
Mounts in EIA standard 19 in. telco rack or equipment cabinet with included 2-post rack kit |
| Other Mounting Options |
Table-top, rack-mount, wall-mount (ports up or down), under-table mounting with provided brackets |
| Important Note |
Must be mounted top surface up to ensure long-term reliability; avoid upside-down mounting |
