| I/O ports and slots |
- 8 RJ-45 autosensing 10/100/1000 Class 4 PoE ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
- Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
- 2 SFP 1GbE ports
|
| Dimension |
10(w) x 10(d) x 1.73(h) in (25.4 x 25.4 x 4.39 cm) (1U height) |
| Processor and memory |
ARM Cortex-A9 @ 800 MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5 MB |
| Throughput (Mpps) |
14.88 Mpps |
| Switching capacity |
20 Gbps |
| Operating temperature |
32°F to 104°F (0°C to 40°C) |
| Operating relative humidity |
15% to 95% @ 104°F (40°C) |
| Nonoperating/Storage temperature |
-40°F to 158°F (-40°C to 70°C) |
| Nonoperating/Storage relative humidity |
15% to 95% @ 140°F (60°C) |
| Altitude |
up to 10,000 ft (3 km) |
| Idle power |
11.7 W |
| PoE |
124 W Class 4 PoE |
| Power Supply |
Internal power supply |
