Thông số kỹ thuật
| General Description | |
|---|---|
| Description | SRX300 Services Gateway includes hardware (8GE, 4G RAM, 8G Flash, power adapter and cable) and Junos Software Base (Firewall, NAT, IPSec, Routing, MPLS and Switching). RMK not included |
| Junos OS software version tested | Junos OS 15.1X49 |
| Form factor | Desktop |
| Performance & Capacity | |
| Firewall performance (max) | 1 Gbps |
| IPS performance | 100 Mbps |
| AES256+SHA-1 / 3DES+SHA-1 VPN performance | 250 Mbps |
| Maximum concurrent sessions | 64,000 |
| New sessions/second (sustained, TCP, 3-way) | 5,000 |
| Maximum security policies | 1000 |
| Maximum security intelligence data feed entries in firewall rules database | N/A |
| Interfaces & Ports | |
| Total onboard ports | 8x1GbE |
| Onboard RJ-45 ports | 6x1GbE |
| Onboard SFP ports | 2x1GbE |
| MACsec-capable ports | 2x1GbE |
| Out-of-band (OOB) management ports | 0 |
| Mini PIM (WAN) slots | 0 |
| Console (RJ-45 + miniUSB) | 1 |
| USB 3.0 ports (type A) | 1 |
| Optional PoE+ ports | N/A |
| SSD slots | 0 |
| Memory & Storage | |
| System memory (RAM) | 4 GB |
| Storage (flash) | 8 GB |
| Power & Cooling | |
| Redundant PSU | No |
| Power supply | AC (external) |
| Average power consumption | 24.9 W |
| Average heat dissipation | 85 BTU/h |
| Maximum current consumption | 0.346 A |
| Airflow/cooling | Fanless |
| Physical Specifications | |
| Size (WxHxD) | 12.63 x 1.37 x 7.52 in. (32.08 x 3.47 x 19.10 cm) |
| Environment | |
| Operational temperature | -4° to 140° F (-20° to 60° C) |
| Nonoperational temperature | 4° to 158° F (-20° to 70° C) |
| Operating humidity | 10% to 90% noncondensing |
| Nonoperating humidity | 5% to 95% noncondensing |
