Thông số kỹ thuật
| Interfaces | |
|---|---|
| RJ-45 | 8 ports |
| RJ-45 Management | 1 ports |
| Console | 1 ports |
| USB | 2 ports |
| Console – micro – USB | 1 ports |
| Dimensions | |
| Depth | 22.352 cm |
| Height | 4.318 cm |
| Weight | 2.26796 kg |
| Width | 20.575 cm |
| Performance and Capacities | |
| Firewall throughput (HTTP/appmix) | 3.8/3.2 Gbps |
| Threat Prevention throughput (HTTP/appmix) | 1.6/1.7 Gbps |
| IPsec VPN throughput | 12.2 Gbps |
| Max sessions | 300,000 |
| New sessions per second | 52,000 |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Network / Transport Protocol | PPPoE, IPv6 |
| Routing Protocol | RIP, BGP, IGMPv2, IGMP, OSPFv2, PIM-SM, static IP routing, IGMPv3, OSPFv3, PIM-SSM |
| Features | |
| Features | Firewall protection, VLAN support, IPv6 support, URL filtering, fanless, web threat protection, Data Loss Prevention (DLP), SD-WAN support |
| Encryption Algorithm | |
| Encryption Algorithm | Triple DES, MD5, IKE, SSL, SHA-1, 128-bit AES, 192-bit AES, 256-bit AES, IKEv2, 256-bit SHA, 512-bit SHA, 384-bit SHA |
| Compliant Standards | |
| Compliant Standards | IEEE 802.1Q |
