Thông số kỹ thuật
| Physical interfaces | |
|---|---|
| Storage | Integrated 64 GB SSD |
| Ethernet interfaces | 10 x GbE copper 2 x 2.5 GbE copper 2 x SFP fiber |
| Power-over-Ethernet | 2 x 2.5 GbE (30W max. per port) |
| Management ports | 1 x COM RJ45 1 x Micro-USB (cable included) |
| Other I/O ports | 1 x USB 2.0 (front) 1 x USB 3.0 (rear) |
| Number of expansion slots | 1 |
| Performance | |
| Firewall throughput | 11,500 Mbps |
| Firewall IMIX | 4,700 Mbps |
| Firewall Latency (64 byte UDP) | 8 µs |
| IPS throughput | 3,300 Mbps |
| Threat Protection throughput | 1,000 Mbps |
| Concurrent connections | 6,400,000 |
| New connections/sec | 74,500 |
| Xstream SSL/TLS Inspection | 950 Mbps |
| Xstream SSL/TLS Concurrent connections | 18,432 |
| Physical specifications | |
| Mounting | Rackmount kit available (to be ordered separately) |
| Dimensions (Width x Height x Depth) | 320 x 44 x 213 mm |
| Weight | 2.4 kg / 5.29 lbs (unpacked) 4.4 kg / 9.70 lbs (packed) |
| Environment | |
| Power supply | External auto-ranging AC-DC 100-240VAC, 2.5A@50-60 Hz 12VDC, 12.5A, 150W Optional second redundant power supply |
| Power consumption | 30 W/102 BTU/hr (idle) 62 W/212 BTU/hr (max.) PoE addition enabled 76 W/260 BTU/hr (max.) |
| Operating temperature | 0°C to 40°C (operating) -20°C to +70°C (storage) |
| Humidity | 10% to 90%, non-condensing |
| Product Certifications | |
| Certifications | CB, CE, UL, FCC, ISED, VCCI, CCC, KC*, BSMI, NOM, Anatel |
